32585000

EQUES^®60Classic
busbar adapter 500 A, 4-pole
185 x 300
connection to the system top
for: ABB Tmax T5, Allen-Bradley 140G-K
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
More

32581000

EQUES^®60Classic
busbar adapter 500 A, 4-pole
185 x 300
connection to the system top
for: Eaton NZM3-XKR13O
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
More

32583000

EQUES^®60Classic
busbar adapter 500 A, 4-pole
185 x 300
connection to the system top
for: Schneider Electric NS400, NS630, NSX400, NS630
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
More

32033000A

EQUES^®60Classic
busbar adapter 590 A, 4-pole
185 x 300
connection to the system top
for: Siemens 3VA13, 3VA14, 3VA23, 3VA24, 3VA53, 3VA54, 3VA63, 3VA64
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
More

32643000

EQUES^®60Classic
busbar adapter 520 A, 4-pole
185 x 284
connection to the system top or bottom
for: Schneider Electric NSX400, NSX630
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
More

32113000AC

EQUES^®60Classic
busbar adapter 630 A, 4-pole
with laminated copper (top)
184 x 300
phase distance 44 - 48 mm
connection to the system top
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
coming soon
More

32114000AC

EQUES^®60Classic
busbar adapter 630 A, 4-pole
with laminated copper (top)
184 x 300
phase distance 44 - 48 mm
connection to the system top
for: ABB T5, XT5 / Eaton NZM3 / Schneider Electric NSX630 / Siemens 3VA23, 3VA24
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
coming soon
More

32115000AC

EQUES^®60Classic
busbar adapter 630 A, 4-pole
with laminated copper (bottom)
184 x 300
phase distance 44 - 48 mm
connection to the system bottom
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
coming soon
More

32116000AC

EQUES^®60Classic
busbar adapter 630 A, 4-pole
laminated copper
phase distance 44 - 48 mm
for: ABB T5, XT5 / Eaton NZM3 / Schneider Electric NSX630 / Siemens 3VA23, 3VA24
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
NEW
More

32106000AC

EQUES^®60Classic
busbar adapter 400 A, 4-pole
with laminated copper (top)
140 x 300
phase distance 44 - 48 mm
connection to the system top
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
coming soon
More

32107000AC

EQUES^®60Classic
busbar adapter 400 A, 4-pole
with laminated copper (top)
184 x 300
phase distance 44 - 48 mm
connection to the system top
for: Schneider Electric NSX 400
for busbars: 12, 15, 20, 25, 30 x 5, 10 and section busbars
coming soon
More
