The picture may show a similar product.
Référence 37203000A
transformateur de courant 500 A / 5 A
1,5 VA / classe 1
| Groupe de produits | 23 |
| Sous-groupe | 05 |
| Dimensions de l'emballage | 1 |
| EAN | 4021267372033 |
| ECLASS 6.1 | 27210902 |
| ECLASS 7.1 | 27210902 |
| ETIM 4.0 | EC002048 |
| ETIM 5.0 | EC002048 |
Normes
IEC 61869-1:2007
IEC 61869-2:2012
Type: CT1-500-1
Homologation CCC: no certification required
| Taille: | CT1 |
| Details IEC | |
| Normes | |
|
IEC 61869-1:2007 IEC 61869-2:2012 |
| Electrical data IEC | |
| prim. rated current In: | 500 A |
| sec. rated current: | 5 A |
| sec. rated apparent power: | 1.5 VA |
| accuracy class (current): | 1 |
| max. operation voltage Um: | 720 V |
| therm. short-time current Ith: | 30 kA |
| class of insulation: | H |
| over-current limitation factor: | FS5 |
power dissipation of the article:
The power dissipation at a typical load of 80 % results to 2,7 W.
(The power dissipation at full load would be 4,2 W.)
| Charactéristiques mécaniques | |
| L x H x P: | 71 x 78 x 26 |
| Poids: | 10,4 kg/100 |
| CT can be integrated in the device: | ja |
| CT can be integrated in the CT module: | nein |
| sealable: | ja |
| Points de raccordement | |
| cage clamp connection | |
| screw drive: | PZ1 |
| wire stripping: | 12 mm |
| min. cross-section: | 2,5 mm² |
| max. cross-section: | 4 mm² |
| Md min.: | 2,0 Nm |
| Md max.: | 2,0 Nm |
| Not suitable for aluminium cables ! | |
| Not suitable for aluminium cables ! | |
