The picture may show a similar product.
Référence 35007000
unité d'alimentation centrale 1250 A
largeur d'armoire 600 mm
usable busbar length 403 mm
Système
centre feed unit
Avantages produit
Clear construction and undrilled connection technology enable safe and cost-efficient solutions to problems.
Groupe de produits | 11 |
Sous-groupe | 12 |
Dimensions de l'emballage | 1 |
EAN | 4021267350079 |
ECLASS 6.1 | 27370390 |
ECLASS 7.1 | 27370390 |
ETIM 4.0 | EC001900 |
ETIM 5.0 | EC001900 |
Normes
IEC 61439-1:2020
UL 508
Approbations
UL
for UL feeder circuits >250V
Type: CentreFeedUnit
UL file: E123577, UL category (for USA): NMTR https://www.ul.com
UL file: E123577, UL category (for Canada): NMTR7 https://www.ul.com
Homologation CCC: no certification required
Details IEC | |
Normes | |
IEC 61439-1:2020 |
Electrical data IEC | |
Courant assigné (IEC): | 1250 A |
Tension assignée (IEC) CA: | 690 V |
rated isolation voltage Ui AC: | 1000 V |
Tension assignée de tenue aux chocs Uimp: | 8 kV |
rated peak withstand current Ipk max.: | 93 kA |
power dissipation of the article:
The power dissipation at a typical load of 80 % results to 29,7 W.
(The power dissipation at full load would be 46,4 W.)
4-pole busbar system, can be retrofitted |
Details UL | |
Normes | |
UL 508 |
for UL feeder circuits >250V |
Electrical data UL | |
rated current (UL): | 1200 A |
rated voltage (UL) AC: | 480 V |
rated frequency (UL): | 50 / 60 Hz |
SCCR protected max.: | 45 kA |
with any DIVQ circuit breaker 1200 A / 480 V AC |
Charactéristiques mécaniques | |
L x H x P: | 583 x 300 x 300 |
Poids: | 1434,0 kg/100 |
Pôles: | 3 pôles |
Section: | 500 mm² |
Conseils |
The scope of delivery includes: 2 busbar supports, 3 busbars, fastening brackets, fastening screws and holders for covers. |
for UL feeder circuits >250V |
