hammer-head screw for TCC-profile (01379)

The picture may show a similar product.

Description

Part No.: 01379 000

hammer-head screw for TCC-profile

M10 x 45

for subsequent mounting, with nut and spring washer

for busbars TCC section

System

centre feed unit

Product group 07
Subgroup 29
pack size 12
EAN 4021267013790
ECLASS 6.1 27371392
ECLASS 7.1 27371392
ETIM 4.0 EC002498
ETIM 5.0 EC002498

Approvals

Standards

IEC 61439-1:2020

CCC approval: no certification required

Technical data

Details IEC
Standards
IEC 61439-1:2020
Mechanical data
weight: 5.1 kg/100
for busbars: TCC section
Terminal points
screw connection
M10
Not suitable for aluminium cables !
Terminal space: M10 x 45

Application notes

Not suitable for aluminium cables !

Tightening torque 30 Nm
