La imagen puede mostrar un producto similar.
Part No.: 33695000A
cubrebornes 3 polos
para SD2-3, SD2-4
| grupo de producto | 14 |
| subgrupo | 51 |
| embalaje | 1 |
| EAN | 4021267336950 |
| ECLASS 6.1 | 27371492 |
| ECLASS 7.1 | 27371492 |
| ETIM 4.0 | EC002498 |
| ETIM 5.0 | EC002498 |
Normas
IEC 60947-1:2020
IEC 60947-3:2020 AC ratings only
UL 60947-4-1
homologaciónes
UL
tipo: SD2-C-3
UL file: E506215, UL category (for USA): NLRV https://www.ul.com
UL file: E506215, UL category (for Canada): NLRV7 https://www.ul.com
| datos IEC | |
| Normas | |
|
IEC 60947-1:2020 IEC 60947-3:2020 AC ratings only |
| datos UL | |
| Normas | |
| UL 60947-4-1 |
| datos electricos UL | |
| for wires UL: | Cu 75°C |
| datos mecánicos | |
| peso: | 2,2 kg/100 |
| Polaridad: | 3 polos |
| puntos de apriete | |
| min. cross-section UL: | AWG 6 |
| max. cross-section UL: | AWG 1 |
| torque (UL): | 31 lb-in |
| for wires UL: | Cu 75°C |
|
Notas |
Two connection space covers are necessary for each the top and the bottom of a 3P+N switch: 3-pole and 1-pole. |
| short-circuit withstandability: | not applicable, since the product does not contain or carry any live parts or is not stressed in the case of a short-circuit |
