The picture may show a similar product.
Référence 01252000
couvercle de jeu de barres
pour des profils en double et triple T, longueur 1 m
cache de protection contre les contacts
Système
60Classic, centre feed unit
Groupe de produits | 06 |
Sous-groupe | 27 |
Dimensions de l'emballage | 5 |
EAN | 4021267012526 |
ECLASS 6.1 | 27370390 |
ECLASS 7.1 | 27142190 |
ETIM 4.0 | EC002270 |
ETIM 5.0 | EC002270 |
Normes
IEC 61439-1:2020
UL 508
Approbations
CSA , UL , DNV GL
for UL feeder circuits >250V
Type: CHH-L
UL file: E123577, UL category (for USA): NMTR https://www.ul.com
UL file: E123577, UL category (for Canada): NMTR7 https://www.ul.com
CSA file: 110285, CSA class: 3211-37 https://directories.csa-international.org
Homologation CCC: no certification required
Details IEC | |
Normes | |
IEC 61439-1:2020 |
Details UL | |
Normes | |
UL 508 |
for UL feeder circuits >250V |
Charactéristiques mécaniques | |
L x H x P: | 1000 x 35 x 78 |
Poids: | 38,0 kg/100 |
Conseils |
When processing and using the plastic sections, avoid contact with oils, greases and similar chemicals. |
short-circuit withstandability: | not applicable, since the product does not contain or carry any live parts or is not stressed in the case of a short-circuit |
for UL feeder circuits >250V |
