switch disconnector with fuses, 3-pole (33338)

The picture may show a similar product.

Description

Part No.: 33338 000

CAPUS^®Panel

switch disconnector with fuses, 3-pole

screw M10, graphite-grey handle

NH 1, 250 A

for mounting plate

ERGONFUSE-250

System

Panel

Advantages of the product

double-breaking main contacts, visible separation sections, user-independent switching, voltage-free exchange of fuses, assembly and connection material contained in scope of delivery.

Product group	15
Subgroup	06

pack size	1
EAN	4021267333386

ECLASS 6.1	27371401
ECLASS 7.1	27371401
ETIM 4.0	EC001040
ETIM 5.0	EC001040

Approvals

Standards

IEC 60947-1:2020
IEC 60947-3:2020 AC ratings only

Approvals

IEC (CB)

type number: LTS-F250

Technical data

for fuse links size:	NH 1
fuse links acc. to standard:	IEC / HD 60269-2
permitted power dissipation of the fuse-link:	23 W

Details IEC
Standards
IEC 60947-1:2020 IEC 60947-3:2020 AC ratings only

Electrical data IEC
rated current (IEC):	250 A
rated voltage (IEC) AC:	690 V

rated isolation voltage U_i AC:	1000 V
rated surge voltage U_imp :	8 kV

Utilisation category AC (IEC 60947-3) :

AC-23B (690V)
AC-22B (690V)
AC-21B (690V)

cond. short-circuit current with fuses (AC):	80 kA / 690 V
approved wth fuse links of operation class:	gG

power dissipation of the article:

The power dissipation at a typical load of 80 % results to 28.8 W.

(The power dissipation at full load would be 45.0 W.)

Mechanical lifespan (switching operations) 7000
conv. therm. current in housing 250 A, horizontal installation (adjacent poles) encapsulated 504 x 378 x 302mm 250 A, vertical installation (poles beneath each other) encapsulated 500 x 500 x 300mm
Shock protection at front with terminal space cover IP20 for fuse links DIN 43620 size 1 up to 23W power dissipation

Mechanical data
W x H x D:	270 x 232 x 253
weight:	726.0 kg/100
poles:	3-pole
Mounting:	for mounting plate

Terminal points
screw connection
M10
Md min.:	25.2 Nm
Md max.:	30.8 Nm
Not suitable for aluminium cables !
lam. Cu width:	15 - 30 mm
lam. Cu thickness:	1 - 10 mm

Application notes

Not suitable for aluminium cables !
When installing a cover, the switch-disconnector on the housing must not be closed, the safety instructions for the Emergency Stop switch must be observed.

permitted power dissipation of the fuse-link:	23 W
